We’ll demonstrate this technique by creating a simple archway in Blender, after which we’ll set up a small scene, finally we will render the scene in parts, using a shader to determine what parts to draw fully opaque and what parts to make transparent.
So let’s fire up trusty old blender! Now mind you I’m not a modeler so I’m going to create the simplest archway that there was ever built:
Yes, that’s it, just two cubes stretched and skewed a bit. The lower cube is going to be always visible while the upper cube (aka archway) is going to be made partially transparent when it’s in front of our player. You’ll have to export and store them separately. I’ve exported my lower part as pilar.fbx and the upper part as arc.fbx.
Also create a simple sphere and export it as cut.fbx, we’ll use the sphere to cut away parts that obstruct our view of the player
Now let’s write some code, create a new XNA 4.0 PC project. Add the arc.fbx, pilar.fbx and cut.fbx to the content project. Then create some members and load them:
private Model arc;
private Model pillar;
private Model cut;
private Model player; // just a cube as well
protected override void LoadContent()
{
// ... //
arc = Content.Load("arc");
pillar = Content.Load("pillar");
cut = Content.Load("cut");
player = Content.Load("pillar");
}
Now we’re going to set up our scene, we’ll divide it in a low part, which will include the floor, the pillar and the player. We’ll also make a high part where the tall part of walls, archways and roofs will be drawn. We’ll draw the low part and the high part to different render targets. Create a member RenderTarget2D[] rts; in Game1.cs and add the following code in LoadContent()
rts = new RenderTarget2D[]
{
new RenderTarget2D(GraphicsDevice, GraphicsDevice.Viewport.Width, GraphicsDevice.Viewport.Height, false, SurfaceFormat.Color, DepthFormat.Depth16),
new RenderTarget2D(GraphicsDevice, GraphicsDevice.Viewport.Width, GraphicsDevice.Viewport.Height, false, SurfaceFormat.Color, DepthFormat.Depth16)
};
We now have two render targets, let’s make two methods and a little helper method in Game1.cs to draw the pillar, ground and player to rt[0] and the arc to rt[1]:
private void RenderHighObjectsAndRoofs()
{
GraphicsDevice.SetRenderTarget(rts[1]);
GraphicsDevice.Clear(Color.Transparent);
DrawColoredModel(arc, Matrix.Identity, Color.Red);
}
private void RenderLowObjectsAndPlayer(GameTime gameTime)
{
GraphicsDevice.SetRenderTarget(rts[0]);
GraphicsDevice.Clear(Color.Transparent);
Matrix groundMatrix = Matrix.CreateTranslation(new Vector3(0, -40f, 0)) *
Matrix.CreateScale(new Vector3(10, 0.1f, 10));
Matrix playerMatrix = Matrix.CreateScale(new Vector3(0.5f, 0.25f, 0.5f)) *
Matrix.CreateTranslation(new Vector3(5, 0, 0)) *
Matrix.CreateRotationY((float)gameTime.TotalGameTime.TotalSeconds);
DrawColoredModel(pillar, groundMatrix, Color.Gray);
DrawColoredModel(pillar, Matrix.Identity, Color.Green);
DrawColoredModel(player, playerMatrix, Color.Yellow);
}
private void DrawColoredModel(Model model, Matrix worldMatrix, Color color)
{
foreach (ModelMesh mesh in model.Meshes)
{
foreach (BasicEffect effect in mesh.Effects)
{
effect.World = model.Bones[mesh.ParentBone.Index].Transform * worldMatrix;
effect.View = camera.ViewMatrix;
effect.Projection = camera.ProjectionMatrix;
effect.LightingEnabled = false;
effect.DiffuseColor = color.ToVector3();
}
mesh.Draw();
}
}
Let’s see if everything went well so far, set up a camera (for a sample camera and set up of that camera see the attached source code) and add the following code to the Draw method in Game1.cs
RenderLowObjectsAndPlayer(gameTime);
RenderHighObjectsAndRoofs();
GraphicsDevice.SetRenderTarget(null);
GraphicsDevice.Clear(Color.CornflowerBlue);
spriteBatch.Begin(SpriteSortMode.Immediate, BlendState.AlphaBlend,
SamplerState.LinearClamp, DepthStencilState.Default, RasterizerState.CullNone);
spriteBatch.Draw(rts[0], new Rectangle(0, 0, GraphicsDevice.Viewport.Width / 2,
GraphicsDevice.Viewport.Height / 2), Color.White);
spriteBatch.Draw(rts[1], new Rectangle(GraphicsDevice.Viewport.Width / 2, 0,
GraphicsDevice.Viewport.Width / 2, GraphicsDevice.Viewport.Height / 2),
Color.White);
spriteBatch.End();
//snip
Run the game, you should now see something like this:
As you can see the scene is nicely rendered in two parts, left the parts that are low and on the right the parts that are high. Great! We’ll now add a 3rd render target. In this render target we’re going to decide what part of the right screen to cut away and what part to keep.
cut = Content.Load("cut");
Change the construction of rts in LoadContent() to this:
rts = new RenderTarget2D[]
{
new RenderTarget2D(GraphicsDevice, GraphicsDevice.Viewport.Width,
GraphicsDevice.Viewport.Height, false, SurfaceFormat.Color, DepthFormat.Depth16),
new RenderTarget2D(GraphicsDevice, GraphicsDevice.Viewport.Width,
GraphicsDevice.Viewport.Height, false, SurfaceFormat.Color, DepthFormat.Depth16),
new RenderTarget2D(GraphicsDevice, GraphicsDevice.Viewport.Width,
GraphicsDevice.Viewport.Height, false, SurfaceFormat.Color, DepthFormat.Depth16)
};
Now let’s create another helper method, this time to draw to rt[2] exactly what part of the screen should never be obstructed by what’s in rt[1]:
private void RenderCutOutShape(GameTime gameTime)
{
GraphicsDevice.SetRenderTarget(rts[2]);
GraphicsDevice.Clear(Color.White);
Matrix cutMatrix = Matrix.CreateScale(2.0f) *
Matrix.CreateTranslation(new Vector3(5, 0, 0)) *
Matrix.CreateRotationY((float)gameTime.TotalGameTime.TotalSeconds);
DrawColoredModel(cut, cutMatrix, Color.Black);
}
Notice that we scale up the sphere a little bit so that it’s bigger than the player, it also moves along the same path as the player, the scale of the cut is something that you’ll probably want to tweak later to give the best result. Make it larger to give the player a better view of the player character and the enemies around him, make it smaller for an extra claustrophobic effect.
Anyway let’s draw this render target to the 3rd quadrant of our screen. Change the code in your draw method to this:
RenderLowObjectsAndPlayer(gameTime);
RenderHighObjectsAndRoofs();
GraphicsDevice.SetRenderTarget(null);
GraphicsDevice.Clear(Color.CornflowerBlue);
spriteBatch.Begin(SpriteSortMode.Immediate, BlendState.AlphaBlend,
SamplerState.LinearClamp, DepthStencilState.Default, RasterizerState.CullNone);
spriteBatch.Draw(rts[0], new Rectangle(0, 0, GraphicsDevice.Viewport.Width / 2,
GraphicsDevice.Viewport.Height / 2), Color.White);
spriteBatch.Draw(rts[1], new Rectangle(GraphicsDevice.Viewport.Width / 2, 0,
GraphicsDevice.Viewport.Width / 2, GraphicsDevice.Viewport.Height / 2),
Color.White);
spriteBatch.Draw(rts[2], new Rectangle(0, GraphicsDevice.Viewport.Height / 2,
GraphicsDevice.Viewport.Width / 2, GraphicsDevice.Viewport.Height / 2),
Color.White);
spriteBatch.End();
//snip
In the bottom left part of the screen you should see a white square with a black sphere moving exactly like the yellow cube that represents our player in the top left part of the screen.
Great! Now all we need to do is combine these 3 pictures. Let’s write a simple shader. This shader picks for each position a pixel from either rt[0] or rt[1] based on the alpha value of the pixel in rt[1] and whether rt[2] is black or white.
Create a new effect file in your content project, clear all autogenerate text and then write the following shader:
sampler lowSampler : register(s0);
texture highTexture;
sampler highSampler = sampler_state
{
Texture = (highTexture);
};
texture cutTexture;
sampler cutSampler = sampler_state
{
Texture = (cutTexture);
};
float4 PixelShaderFunction(float2 texCoord: TEXCOORD0) : COLOR0
{
float4 baseColor = tex2D(lowSampler, texCoord).rgba;
float4 highColor = tex2D(highSampler, texCoord).rgba;
float cutColor = tex2D(cutSampler, texCoord).r;
if(cutColor < 1) { return baseColor + highColor * cutColor; } else { if(highColor.a > 0)
{
return highColor;
}
else
{
return baseColor;
}
}
}
technique CutAway
{
pass Pass1
{
PixelShader = compile ps_2_0 PixelShaderFunction();
}
}
Now to display some results, add a new member “Effect cutAwayEffect” to Game1.cs and initialize it in the LoadContent() method by adding the following line to it:
cutAwayEffect = Content.Load("CutAwayEffect");
Then add the following code to the end of the Draw method, right before base.Draw()
cutAwayEffect.Parameters["highTexture"].SetValue(rts[1]);
cutAwayEffect.Parameters["cutTexture"].SetValue(rts[2]);
cutAwayEffect.Parameters["blurWidth"].SetValue(0.07f);
spriteBatch.Begin(SpriteSortMode.Immediate, BlendState.AlphaBlend, null, null, null,
cutAwayEffect);
spriteBatch.Draw(rts[0], new Rectangle(GraphicsDevice.Viewport.Width / 2,
GraphicsDevice.Viewport.Height / 2, GraphicsDevice.Viewport.Width / 2,
GraphicsDevice.Viewport.Height / 2), Color.White);
spriteBatch.End();
You should now see that a spherical part of the archway becomes transparent every time the player passes under it:
Now this effect is quite harsh, not like the smooth effect of Diablo 3 at all. So let’s soften it a bit. In the shader add a nice radial blur function (adapted from the nVidia shader library) above the pixel shader function.
float4 RadialBlur(float2 texCoord, sampler2D tex)
{
float4 c = 0;
float modifier = 0.08;
// this loop will be unrolled by compiler and the constants precalculated:
for(int i= -NSAMPLES / 2.0; i < NSAMPLES / 2.0; i++) {
float scale = modifier * (i / (float)(NSAMPLES - 1.0));
c += tex2D(tex, texCoord.xy*scale + texCoord);
}
c /= NSAMPLES;
return c;
}
And change the PixelShaderFunction to this:
float4 PixelShaderFunction(float2 texCoord: TEXCOORD0) : COLOR0
{
float4 baseColor = tex2D(lowSampler, texCoord).rgba;
float4 highColor = tex2D(highSampler, texCoord).rgba;
float cutColor = tex2D(cutSampler, texCoord).r;
if(cutColor < 1 && highColor.a > 0)
{
float3 blend = RadialBlur(texCoord, cutSampler).rgb;
float3 mix = lerp(baseColor.rgb, highColor.rgb, blend);
return float4(mix, 1);
}
else
{
if(highColor.a > 0)
{
return highColor;
}
else
{
return baseColor;
}
}
}
This should give us a lot smoother effect:
You can tweak the smoothness of this effect by modifying the ‘modified’ variable in the RadialBlur function, try some higher values for modifier together with a bigger cut object and your result will get smoother, but there will be more cut away from the scene.
Now that we've got the basics covered you can try to:
- Use weird objects as cut out
- Smooth in the blur effect over time
- Cut away entire parts in full instead of cutting a circle out of them
Anyway that concludes this tutorial. I’m very interested how you will extend it so leave a couple of screenshots at the bottom of the page!
